Compact 24 Snowblower with Autoturn
Designed for effortless agility while maintaining 100% Ariens® ability, the Compact Sno-Thro® is designed to be easy enough to take out for a light dusting of snow and reliable enough to tackle up to 59 tons per hour if needed. A 2.5X Quick-Turn chute rotation throws the snow where you want it. Its 24” all-steel housing and serrated 11” auger chew through huge drifts with ease. Don’t let its convenient size fool you, there’s a lot of power packed into the Ariens Compact.
Overview
- Ariens AX 223CC engine with electric start
- Strong cast-iron gear case
- Compact, user-friendly design with Auto-Turn for easy operation
SPECIFICATION
|
Power Train |
|
|
Engine |
Ariens AX® |
|
Starting System |
120v / Electric |
|
Steering |
Auto-Turn |
|
Drive Type |
Disc-O-matic |
|
Speeds |
6 Forward/2 Reverse |
|
Tire Size |
15 In / 38.1cm |
|
Tire Type |
Directional Snow Tread |
|
Clearing Specs |
|
|
Clearing Width (in/cm) |
24 In / 60.9cm |
|
Housing Height |
20 In / 50.7cm |
|
Throwing Distance |
3 ft - 40 ft |
|
Chute Rotation |
2.5x Quick Turn |
|
Chute Turning Radius |
205 |
|
Deflector Control |
In-Dash Lever |
|
Stage Type |
Two Stage |
|
Auger Diameter |
11 In / 27.9cm |
|
Auger Type |
Steel Serrated |
|
Impeller Profile |
Steel 3 Blade |
|
Impeller Diameter |
12 In / 30.4cm |
|
Skid Shoes |
Steel Reversible |
|
Scraper Bar |
Steel Adjustable |
|
Gear Case |
Cast Iron |
|
Dimensions |
|
|
Length |
53.3 In / 135.3cm |
|
Width |
26.4 In / 67cm |
|
Height |
44 In / 111.7cm |
|
Weight (assembled) |
187 lb / 84.8 kg |
|
Warranties |
|
|
Product Warranty |
3 years residential use. 90 days commercial use |
|
Gear Case Warranty |
5 Year Consumer, 1 Year Commercial |
|
Accessories |
|
|
Features at a Glance |
Light Type: Halogen Handwarmers: Optional Remote Deflector Control: Standard Drift Cutters: Optional One Hand Interlock: Standard |
